Symmetrical carbon 27.5er mountain bike wheel parts 40mm wide fat AM bike rims TMC730 |
| |
Model : TMC730 |
|
Size:27.5ER / 650b |
| |
Rims type : AM tubeless ready carbon rims |
|
ERD: 594 mm |
| |
Material : T800 + T700 carbon fibers |
|
Width: 35/40 mm |
| |
Warranty : 2 Years |
|
Depth : 30 mm |
| |
Spoke Hole Dia.: 2.3mm, 4.5mm |
|
Weight : XC:400±15g,AM:450±15g |
| |
Valve Hole Dia.: 6.5mm (Presta) |
|
Assembly Hole Dia.: 8.0mm |
| |
Rims offset: 2.5mm |
|
Hole count: 18,20,24, 28, 32,36 |
| |
Weave : ud / 3k / 12k |
|
Application: XC / AM |
| |
Tire Size: 1.7" ~ 2.15" |
|
Max Spoke Tension: 130kgf |
| |
Weight Limit: 100kg |
|
Max Tire Pressure:
≤60psi recommended |
| |
|
|
|
 |
| |
 |
| tubeless rim bead |
 |
| |
 |
| |
 |
| |
|
|
|
 |
| |
|
|
|
 |
| |
|
|
|
| |
Characteristics : |
|
|
| |
1. Design for AM version bike wheels. |
|
4.In normal , the rims without logo . But we can painting your own logo . |
| |
2 .This model can be use for 27.5er / 650B. |
|
5.This rim will give you a more reliable tubeless fit. |
| |
3.mtb XC / AM used ,Reduce weight without affecting performance. |
|
|
| |
|
|
|
